Applications
| Model | CAW 7KE-DCGS | CAW 11KE-DCGS | CAW 22KE-DCGS |
| Electrical index | |||
| Power connection | 1P+N+PE | 3P+N+PE | 3P+N+PE |
| Input/output voltage | 230VAC±10% | 400VAC±10% | 400VAC±10% |
| Frequency | 50HZ±10% | ||
| Rated power | 7KW | 11KW | 22KW |
| Rated current | 32A | 16A | 32A |
| General Specifications | |||
| Shell material | Hot-dip galvanized steel sheet | ||
| Charging mode | IEC 61851-1 Charging model-3 | ||
| AC plugs | IEC 62196-2 AC Type2 | ||
| Display | 4.3”TFT Color touch screen | ||
| RFID system | Mifare (Classic, DesFire EV1) or others on request | ||
| Communication | GPRS /LAN/Wi-Fi | ||
| Communication Protocols | OCPP (optional: others) | ||
| Place of installation | Indoor and outdoor | ||
| Altitude | ≤3000m | ||
| Protection grade | IP54 | ||
| Operating Temperature | -20-50℃ | ||
| Storage Temperature | -40-70℃ | ||
| Humidity | 5%~95% without condensation | ||
| Cooling mode | Natural cooling | ||
| Length of charging gun cable | 5m(optional) | ||
| Dimensions(W*D*H) | 280mm*120mm*400mm | （结构待定） | （结构待定） |
| Weight | 7.5kg | （待定）kg | （待定）kg |
